Keysight's InfiniiVision 4000 X‑Series Oscilloscopes

Written by Jasmina Filipovic November 10, 2023 Oscilloscopes, Instruments, Keysight

Keysight's InfiniiVision 4000 X‑Series Oscilloscopes

See more of your signal

Get a Quote

Do you already own this product?
Get technical support → here.

Highlights

View More Signal Detail

The Keysight InfiniiVision 4000 X-Series oscilloscopes are designed for next-generation performance, delivering waveform update rates 20 times faster than the competition. A large 12.1" capacitive touch screen combined with innovative hardware-based zone touch triggering makes it easy to capture and view your signals. With the 4000 X-Series, you can be confident that you will catch even the rarest glitches and see more.

The PathWave BenchVue oscilloscope software for remote control, data logging and automated testing
Achieve bandwidths from 200 MHz to 1.5 GHz
See the most signal detail with 1,000,000 waveforms/second update rate
Isolate signals in seconds with zone-touch triggering
Test quickly with simplified operation and an intuitive user interface enabled by a large 12.1" capacitive touch screen
Decode serial buses faster with hardware-based serial analysis options

Key Specifications

Bandwidth
200 MHz to 1.5 GHz

Channels
2 or 4 analog
+16 digital (MSO models)

Max Sample Rate
5 GSa/s

Waveform Update Rate
1,000,000 wvfm/sec

Max Memory Depth
4 M points

Want to see more specifications?

View Data Sheet

Measure More Efficiently

A large 12.1" touchscreen combined with a host of advanced features gives you greater insight:

Turn the most advanced triggering into a simple step with zone touch triggering. Simply draw a box on the screen with your finger
Get more from your oscilloscopes with 7-in-1 instrument integration - oscilloscope, frequency response analyser (Bode plots), logic analyser / mixed-signal oscilloscope (MSO), protocol analyser, dual WaveGen (arbitrary waveform generator), voltmeter and frequency counter
Catch the rarest of glitches with a 1,000,000 waveforms/second update rate
Automate tests and collect data with standard PathWave BenchVue oscilloscope software

PathWave BenchVue Oscilloscopes Software from Keysight

Intuitively control your oscilloscopes, capture screenshots, and log data measurements for more efficient analysis.

Connect and control your scopes from the cloud.
Export results in three clicks to popular tools such as MATLAB, Microsoft Excel or Word for documentation or further analysis.
Visualize multiple types of instrument measurements simultaneously.
Quickly create automated test sequences with minimal instrument knowledge.
Receive a KeysightCare software support subscription and licence with every new instrument purchase.

Find the Model That's Right for You

Model	Bandwidth	Max sample rate	Channels	Memory
DSOX4022A	200 MHz	5 GSa/s	4 Mpts	2
MSOX4022A	200 MHz	5 GSa/s	4 Mpts	2 + 16
DSOX4024A	200 MHz	5 GSa/s	4 Mpts	4
MSOX4024A	200 MHz	5 GSa/s	4 Mpts	4 + 16
DSOX4032A	350 MHz	5 GSa/s	4 Mpts	2
MSOX4032A	350 MHz	5 GSa/s	4 Mpts	2 + 16
DSOX4034A	350 MHz	5 GSa/s	4 Mpts	4
MSOX4034A	350 MHz	5 GSa/s	4 Mpts	4 + 16
DSOX4052A	500 MHz	5 GSa/s	4 Mpts	2
MSOX4052A	500 MHz	5 GSa/s	4 Mpts	2 + 16
DSOX4054A	500 MHz	5 GSa/s	4 Mpts	4
MSOX4054A	500 MHz	5 GSa/s	4 Mpts	4 + 16
DSOX4104A	1 GHz	5 GSa/s	4 Mpts	4
MSOX4104A	1 GHz	5 GSa/s	4 Mpts	4 + 16
DSOX4154A	1.5 GHz	5 GSa/s	4 Mpts	4
MSOX4154A	1.5 GHz	5 GSa/s	4 Mpts	4 + 16
